scale2

Attempt to select nice scale numbers when setting n ticks on a lim axis range.

Usage

scale2(n, lim, kind = "approx", lib.path = NULL, safer_check = TRUE)

Arguments

n

Single positive and non null integer value indicating the desired number of main ticks on the axis.

lim

Vector of 2 numbers indicating the limit range of the axis. Order of the 2 values matters (for inverted axis). Can be log transformed values.

kind

Single character string. Either "approx" (approximative), "strict" (strict) or "strict.cl" (strict clean). If "approx", use the scales::trans_breaks() function to provide an easy to read scale of approximately n ticks spanning the range of the lim argument. If "strict", cut the range of the lim argument into n + 1 equidistant part and return the n numbers at each boundary. This often generates numbers uneasy to read. If "strict.cl", provide an easy to read scale of exactly n ticks, but sometimes not completely spanning the range of the lim argument.

lib.path

Character vector specifying the absolute pathways of the directories containing the required packages if not in the default directories. Ignored if NULL.

safer_check

Single logical value. Perform some "safer" checks (see https://github.com/safer-r)? If TRUE, checkings are performed before main code running: 1) R classical operators (like "<-") not overwritten by another package because of the R scope and 2) required functions and related packages effectively present in local R lybraries. Set to FALSE if this fonction is used inside another "safer" function to avoid pointless multiple checkings.

Value

A vector of numbers.

Author

Gael Millot <gael.millot@pasteur.fr>

Yushi Han <yushi.han2000@gmail.com>

Haiding Wang <wanghaiding442@gmail.com>

Examples

# approximate number of main ticks

ymin = 2 ;
ymax = 3.101 ;
n = 5 ;
scale <- scale2(n = n, lim = c(ymin, ymax), kind = "approx") ;
scale ;
#> [1] 2.0 2.2 2.4 2.6 2.8 3.0
par(yaxt = "n", yaxs = "i", las = 1) ;
plot(ymin:ymax, ymin:ymax, xlim = base::range(scale, ymin, ymax)[order(c(ymin, ymax))], ylim = base::range(scale, ymin, ymax)[order(c(ymin, ymax))], xlab = "DEFAULT SCALE", ylab = "NEW SCALE") ;
par(yaxt = "s") ;
axis(side = 2, at = scale)
